- 1c
代 号
PART NO.
螺 纹 THREAD
管子外径 TUBE O.D.
尺 寸 DIMENSIONS
压力等级
MPa
E
F
D1
D2
l1
L1
S1
S2
S3
1C-12
M12X1.5
M12X1.5
6
6
10
39
12
14
14
31.5 轻系列 L
1C-14
M14X1.5
M14X1.5
8
8
11
40
14
17
17
1C-16
M16X1.5
M16X1.5
10
10
13
42
17
19
19
1C-18
M18X1.5
M18X1.5
12
12
14
43
19
22
22
1C-22
M22X1.5
M22X1.5
15
15
16
46
24
27
27
1C-26
M26X1.5
M26X1.5
18
18
16
48
27
32
32
1C-30
M30X2
M30X2
22
22
20
52
32
36
36
16
轻系列L
L
1C-36
M36X2
M36X2
28
28
21
54
41
41
41
1C-45
M45X2
M45X2
35
35
20
63
46
50
50
1C-52
M52X2
M52X2
42
42
21
66
55
60
60
1D-14
M14X1.5
M14X1.5
6
6
16
45
14
17
17
63
重系列 S
1D-16
M16X1.5
M16X1.5
8
8
18
47
17
19
19
1D-18
M18X1.5
M18X1.5
10
10
17
49
19
22
22
1D-20
M20X1.5
M20X1.5
12
12
19
51
22
24
24
1D-22
M22X1.5
M22X1.5
14
14
22
57
24
27
27
1D-24
M24X1.5
M24X1.5
16
16
21
57
27
30
30
40 重系列 S
1D-30
M30X2
M30X2
20
20
23
66
32
36
36
1D-36
M36X2
M36X2
25
25
26
74
41
46
46
1D-42
M42X2
M42X2
30
30
27
80
46
50
50
1D-52
M52X2
M52X2
38
38
29
90
55
60
60
31.5重系列S
注：如需带卡套及卡套螺母整套订货，则请在代号后加“RN”,如1C9-30RN。
Note：In case if you are interested to order the adapter in complete set with cutting ring and nut ,it is necessary
to insert suffix "RN" after our part no.，for example 1C9-30RN.
